Glory NMD100 Dispenser Notes And Media Dispenser ATM Spare Parts
With the lowest reject rate on the market, the Glory NMD100 guarantees maximum uptime and consistent, front or rear delivery of up to 100 banknotes per bundle. Offering up to eight cassettes, each holding up to 3000 notes, the NMD100 provides extensive functionality and flexibility for your customers wherever they are deploying your solutions.
| Speed range | 7 – 8 notes per second |
|---|---|
| Document size range | Width: 58 – 92 mm Length: 100 – 181 mm Thickness: 0.06 – 0.32 mm |
| Maximum transaction size | 100 ATM fit banknotes |
| Capacity | 1 to 8 cassettes configurable Short cassette: 240 mm or 2000 banknotes Long cassette: 340 mm or 3000 banknotes A separate reject cassette: 250 banknote |
| Connectivity | RS232C connection as standard Integrated shutter interface to control your own shutter Option: plug and play shutter |
| Power supply | 120 – 240V AC, 50/60 Hz, 3A Fitted with integrated power supply |
| Operating environment | Temperature: 5–50°C, 41–122°F Relative humidity: 10–85% non-condensing *operating time above 45 degrees should be limited to less than 10% of product life |
| Dimensions (H × W × D) | 530* × 292 × 549 mm *height shown for 2 denomination with 85 mm throat extension, for each additional denomination add 128 mm |
| Throat extensions | Standard configuration 85 mm Throat extension kits for 130, 180 and 320 mm available (for rear service only) |
| Weight (without notes) | Standard 2 denomination with cassettes: 22.2 kg/48.9 lbs Additional denominations Without cassette: 3.0 kg/6.6 lbs Short cassette (optional): 2.2 kg/4.9 lbs Long cassette (standard configuration): 2.9 kg/6.4 lbs Reject cassette (standard configuration): 2.0 kg/4.4 lbs Reject Box (optional): 1.0 kg/2.2 lbs |
| Manufacturing standards and approvals | RoHS, UL, CE, UKCA |
Based on new issue banknotes, circulated notes will reduce capacity. The performance of polymer notes may reduce at extreme temperature and humidity combinations. Specifications are subject to change without notice.
Contact Us
For inquiries or orders, reach out to our team:
Email: sales@atmpart.com.cn
Tel:+86-0756-5162218
Whatsapp: +86 13926975636
Website: www.tigeratmparts.com
What Glory NMD100 ATM parts we can supply are as below:
| Part Numbers | Description |
|---|---|
| A004348 | NC301 CASSETTE(NMD100) |
| A019207 | RV301 CASSETTE(NMD100) |
| A006541 | NT100 NOTE TRANSPORT |
| A011263 | NQ300 |
| A011261 | Note Feeder NF300 |
| A008646 | Note Diverter (ND200) |
| A008909 | NS200 |
| A008545 | CMC200 Dispenser Control Board |
